CLASS OF INDIVIDUAL - Whole Life Individual

Description

Abstract Concept

A Whole Life Individual is a Bounded Individual that is not the temporal slice of any other Bounded Individual.
A Whole Life Individual includes its past and future.

Examples:

. The Eiffel tower (31st March 1889 - ...).

. William Shakespeare (23 April 1564 - 23 April 1616).

. Confucius (685-758).

. Mount Vesuvius eruption (Aug. 24-25, A.D. 79).

. Oackland digital hospital (1994 - ...).

. The execution of the registration process at the Oackland digital hospital, by John Smith, on 17 March 2020.

Functional Domain: 4D Composite Knowledge Graph

The purpose of the 4D Composite Knowledge Graph is to layer structured spatio-temporal concepts onto the Reflexive Knowledge Graph,

External references

ISO15926 - WholeLifeIndividual

OMG - KerML - Life

Super Types

Bounded Individual (from partition: Structural Partition of Bounded Individual)

Power Type

Whole Life Class

Dictionary

SysFEAT Upper Ontology

RELATIONSHIPS

Simple Graph Graph & Inheritance Table

Simple Graph

Composition: ➝ Classification: ➝ Specialization: ➝ Instance Of: --> Enumerated definition: ➝ Syntax: ➝

Graph & Hierarchy

Composition: ➝ Classification: ➝ Specialization: ➝ Instance Of: --> Enumerated definition: ➝ Syntax: ➝

Relationship Table

Relationship	Cardinality	Target Entity	Source Entity	Description
PowerTyped by Whole Life Class	[1..1]	Whole Life Class	Whole Life Individual
Property of Individual	[*..0]	Class of Property	Bounded Individual	A Classification from a Bounded Individual to a Class of Property that asserts the Bounded Individual has the Class of Property.
End	[*..0]	Temporal Bounding	Bounded Individual	An End is the temporal Exit Border of a Bounded Individual that denotes the end of the Bounded Individual.
Temporal Border	[*..0]	Temporal Bounding	Bounded Individual	Temporal border of a Bounded Individual
Start	[*..0]	Temporal Bounding	Bounded Individual	A Start is the temporal Entry Border of a Bounded Individual that denotes the beginning of the Bounded Individual.
Aggregate Composition	[*..0]	Bounded Individual	Bounded Individual	Aggregate Composition is a reified Composition (Whole/Part) where the composed Bounded Individual becomes a Bounded Member of the whole Bounded Individual.
Temporal Sequencing	[*..0]	Temporal Bounding	Bounded Individual
Referencing Relationship	[*..0]	Entity	Entity	A Referencing Relationship is a Relationship that points at its target Entity through Reference Adjacency.
Dependency Relationship	[1..1]	Entity	Entity	A Dependency Relationship is a Relationship that specifies the existential dependency of the sourceRelationship on its target Relationship.The cardinality to the target Entity is [1..1].
Hierarchical Member	[*..0]	Building Block	Aggregate Block	A Hierarchical Member is an Aggregate Member that is also a Block Lexical Scope for the Building Block it aggregates: it relates its aggregated block by nesting (see Nesting Relationship).Hierarchical Members are used to build hierarchical structures of Building Blocks, in constrast to Block Members which are used to build network structures of Building Blocks.
Block Member	[*..0]	Building Block	Aggregate Block	A Block Member is an Aggregate Member that aggregates its releated Building Block by reference (see Referencing Relationship).Block Members are used to build network structures of Building Blocks while Hierarchical Members are used to build hierarchical structures of Building Blocks.

SERIALIZATION FORMAT

TEXTUAL SYNTAX RDF

File: 342f74b166156e02.rdf

SEMANTIC TAXONOMY

Sub-Types Super-Types

Click node rectangle to collapse/expand one level. Click triangle for full recursive collapse/expand. Double-click on a node to open its URL. Hover for description.

BORDERS

Name	Super type	Border Type	Description
End	Bounded Individual::Temporal Border Bounded Aggregate::Exit Border	Temporal Bounding	An End is the temporal Exit Border of a Bounded Individual that denotes the end of the Bounded Individual.
Start	Bounded Individual::Temporal Border Bounded Aggregate::Entry Border	Temporal Bounding	A Start is the temporal Entry Border of a Bounded Individual that denotes the beginning of the Bounded Individual.
Temporal Border	Bounded Aggregate::Border	Temporal Bounding	Temporal border of a Bounded Individual
